100W Portable Solar Kit

SKU: SWD100-12P

Product Rating:


The 100W portable monocrystalline solar panel kit is the perfect addition to all your camping trips. It is a ready plug and play design with battery clamps included to direct connect to your battery for trickle charging your batteries.

  • Product Code SWD100-12P
  • Maximum power (Pmax) 100W (2x50W panels)
  • Voltage at Pmax (Vmp) 17.8V
  • Current at Pmax (Imp) 5.62A
  • Open-circuit voltage (Voc) 21.30V
  • Short-circuit current (Isc) 6.07A
  • Power tolerance ± 5%
  • Operating temperature -40°C to 85°C
  • Dimensions kit 520mm x 550mm x 30mm (20.47" x 21.65" x 1.18")
  • Weight kit 8.91kg/19.64 lbs
  • Maximum Series Fuse Rating 15A
  • 2-Year Limited Material and Parts Workmanship Warranty

Newpowa offers free shipping for all domestic orders (48 states). Your order will be shipped within 1-2 business days from the date payment is cleared plus transit time, ships from Southern California. Please note that we are unable to ship to PO Box addresses for any size of solar panels. Upon shipment, a tracking number will be provided.

  • 4th Aug 2021 Jack Flanagan


    This panel is built well and works for our overlanding Jeep very well. The case zipper came damaged, however the customer service at Newpowa is awesome and took care of it no questions asked. If your looking for a 100 watt suitcase this is the one!

Write a Review
