New 200W Portable Solar Panel Kit

SKU: NPA200G-12FLD

Product Rating:

Description

Newpowa's New 200W portable solar panel kit is perfect if you are looking for something portable and convenient to use. It comes ready for RV camping and is compatible with most solar generators on the market. No matter where you go, this kit can keep your most important electronic devices powered up and connected to the world.

NPA200G-12FLD Kit Includes

  • 1x 200W portable solar panel
  • 1x 20ft 12AWG cable w/(R/B)
  • 1x Battery Clamp Set with 3ft Wire (NPC-03)
  • 1x 15ft 12AWG XT60 extend cable (NPC-XT60EC)
  • Hinges attached to the unit that allow the unit to close for storage

NPA200G-12FLD-PWM Kit Includes

  • 1x 200W portable solar panel
  • 1x 10A PWM solar charge controller with built-in Bluetooth (NPR-WN20-12P)
  • 1x 20ft 12AWG cable w/(R/B)
  • 1x Battery Clamp Set with 3ft Wire (NPC-03)
  • Hinges attached to the unit that allow the unit to close for storage

NPA200G-12FLD(MPPT) Kit Includes

  • 1x 200W portable solar panel
  • 1x 20A MPPT solar charge controller with built-in Bluetooth (NPR-WN20-24M)
  • 1x 20ft 12AWG cable w/(R/B)
  • 1x Battery Clamp Set with 3ft Wire (NPC-03)
  • Hinges attached to the unit that allow the unit to close for storage
  • Product Code NPA200G-12FLD
  • Maximum power (Pmax) 200W
  • Voltage at Pmax (Vmp) 18.6V
  • Current at Pmax (Imp) 10.8A
  • Open-circuit voltage (Voc) 22.8V
  • Short-circuit current (Isc) 11.2A
  • Temperature coefficient of Voc -0.28%/ °C
  • Temperature coefficient of Isc 0.048%/ °C
  • Temperature coefficient of power -0.35%/ °C
  • NOCT (Air 20°C; Sun 0.8kW/m2 wind 1m/s) 47±2°C
  • Operating temperature -10°C to 65°C

Solar Panel:

  • 1-Year Limited Material and Parts Workmanship Warranty

Charge Controller:

  • 2-Year Limited Material and Parts Workmanship Warranty

Other Accessories:

  • 1-Year Limited Material and Parts Workmanship Warranty

Newpowa offers free shipping for all domestic orders (48 states). Your order will be shipped within 1-2 business days from the date payment is cleared plus transit time, ships from Southern California. Please note that we are unable to ship to PO Box addresses for any size of solar panels. Upon shipment, a tracking number will be provided.
