Pro 200W 12V Monocrystalline Solar Panel

SKU: PRO200S-12I

Product Rating:

Description



Newpowa's Pro Series of Solar Panels

Our Pro 200W 12V Monocrystalline Solar Panel is ideal for bringing power to many different applications when away from the grid. It is commonly used for RVs, Marine, Camping, and many other off-grid applications.

New design:

Built with higher efficiency cells that allow for a better light conversion rate.

9 BusBar Features

  • Under ideal conditions, 9 busbar PV module will outperform the dated 5 and 6 busbar technology. The void space reduction between the 9BB solar cells is designed to enhance the overall efficiency of the PV module by lowering current lengths and mitigating against loss of output.

Key Features

  • Sophisticated all-black design featuring Newpowa badging
  • Advanced 9BB cell technology for unparalleled output & efficiency
  • Maximum Efficiency: 21.5%
  • Nominal 12V DC for standard output
  • Heavy-duty anodized frame with pre-drilled holes for mounting
  • Rugged design to withstand high winds (2400Pa), hail, and snow load (5400Pa)
  • Ridged frame backing for enhanced grip during installation
  • Pre-installed bypass diodes inside the junction box to minimize power drops caused by shading
  • IP-65 rated junction box equipped with 3ft pre-attached wires
  • Product Code PRO200S-12I
  • Maximum power (Pmax) 200W
  • Voltage at Pmax (Vmp) 21.05V
  • Current at Pmax (Imp) 9.51A
  • Open-circuit voltage (Voc) 24.29V
  • Short-circuit current (Isc) 10.03A
  • Temperature coefficient of Voc -(80±10)mV/°C
  • Temperature coefficient of Isc (0.065±0.015)%/ °C
  • Temperature coefficient of power -(0.5±0.05)%/ °C
  • NOCT (Air 20°C; Sun 0.8kW/m2 wind 1m/s) 47±2°C
  • Operating temperature -40°C to 85°C
  • Maximum system voltage 1000V DC
  • Power tolerance ± 3%
  • Maximum Series Fuse Rating 15A
  • 2-Year Limited Material and Parts Workmanship Warranty
  • 10-Year 90% Output Warranty
  • 25-Year 80% Output Warranty

Newpowa offers free shipping for all domestic orders (48 states). Your order will be shipped within 1-2 business days from the date payment is cleared plus transit time, ships from Southern California. Please note that we are unable to ship to PO Box addresses for any size of solar panels. Upon shipment, a tracking number will be provided.
