10A MPPT Waterproof Charge Controller


Product Rating:


Newpowa's waterproof 10A MPPT controller is perfect to be used for marine or any environment that will expose the device with water.

  • Product Code NPR-MPPT1050
  • Max solar/Load current 10A
  • System Voltage 12V
  • Boost voltage 14.5V (25°C)
  • Equalization voltage 14.8V (25°C)
  • Float voltage 13.7V (25°C)
  • Overcharge protect 15.5V
  • Max volt on Bat. terminal 25V
  • Battery type Liquid Gel,AGM(default: Gel)
  • Temperature compensation -4.17mV/K per cell (boost equalization),-3.33mV/K per cell ((float)
  • Output Current 10A
  • Ambient temperature -35 ~ +60 ℃
  • Ambient Humidity 0%-100%RH
  • Net weight (approx.) 260g
  • Dimensions (LxWxH) mm 85.8 x 81 x 23.1 /
  • 2-Year Limited Material and Parts Workmanship Warranty

Newpowa offers free shipping for all domestic orders (48 states). Your order will be shipped within 1-2 business days from the date payment is cleared plus transit time, ships from Southern California. Please note that we are unable to ship to PO Box addresses for any size of solar panels. Upon shipment, a tracking number will be provided.
